psk31beacon.c File Reference

Include dependency graph for psk31beacon.c:


Defines
#define	IO_FLASH_CS PIN_A0
	Flash Chip Select - Port A0.
#define	IO_CUT_DOWN PIN_A1
#define	IO_BALLAST_PUMP PIN_A2
#define	IO_PS0 PIN_A3
#define	IO_UPDATE PIN_A5
#define	IO_CS PIN_B0
#define	IO_PA PIN_B2
#define	IO_GPS_PWR PIN_B3
#define	IO_LED PIN_B4
#define	IO_PS1 PIN_C0
#define	IO_OSK PIN_C2
#define	TIME_DUTYCYCLE_0 0
#define	TIME_DUTYCYCLE_20 2
#define	TIME_DUTYCYCLE_70 7
#define	BALLAST_3D_FIX_COUNT 10
	Number of consecutive 3D GPS fixes required to assert altitude as valid.
#define	BALLAST_HOLD_ALTITUDE 30500l
	Altitude in feet used to control ballast pump.
#define	CUTDOWN_3D_FIX_COUNT 10
	Count of 3D fixes required to assert GPS altitude is valid.
#define	DDS_AD9954_CFR1 0x00
	AD9954 CFR1 - Control functions including RAM, profiles, OSK, sync, sweep, SPI, and power control settings.
#define	DDS_AD9954_CFR2 0x01
	AD9954 CFR2 - Control functions including sync, PLL multiplier, VCO range, and charge pump current.
#define	DDS_AD9954_ASF 0x02
	AD9954 ASF - Auto ramp rate speed control and output scale factor (0x0000 to 0x3fff).
#define	DDS_AD9954_ARR 0x03
	AD9954 ARR - Amplitude ramp rate for OSK function.
#define	DDS_AD9954_FTW0 0x04
	AD9954 FTW0 - Frequency tuning word 0.
#define	DDS_AD9954_FTW1 0x06
	AD9954 FTW1 - Frequency tuning word 1.
#define	DDS_AD9954_NLSCW 0x07
	AD9954 NLSCW - Negative Linear Sweep Control Word used for spectral shaping in FSK mode.
#define	DDS_AD9954_PLSCW 0x08
	AD9954 PLSCW - Positive Linear Sweep Control Word used for spectral shaping in FSK mode.
#define	DDS_AD9954_RWCW0 0x07
	AD9954 RSCW0 - RAM Segment Control Word 0.
#define	DDS_AD9954_RWCW1 0x08
	AD9954 RSCW0 - RAM Segment Control Word 1.
#define	DDS_RAM 0x0b
	AD9954 RAM segment.
#define	DDS_FREQ_TO_FTW_DIGITS 9
	Number of digits in DDS frequency to FTW conversion.
#define	DIAG_BYTES_PER_LINE 32
	Number of bytes per line to display when reading flight data recorder.
#define	GPS_BUFFER_SIZE 50
	The maximum length of a binary GPS engine message.
#define	LOG_WRITE_BUFFER_SIZE 255
	Number of bytes to buffer before writing to flash memory.
#define	PSK_MAX_PACKET 160
	The maximum ASCII length of a PSK 31 message.
#define	PSK31_TIMESLOT 0
	The UTC time in seconds to send a PSK31 data stream.
#define	PSK_SYNC_LENGTH 32
	Number of 0 bits to transmit at start of message.
#define	PSK_END_LENGTH 8
	Number of 0 bits to transmit at end of message.
#define	SERIAL_BUFFER_SIZE 64
	Note this size must be a power of 2, i.e. 2, 4, 8, 16, etc.
#define	SERIAL_BUFFER_MASK 0x3f
	Mask to wrap around at end of circular buffer. (SERIAL_BUFFER_SIZE - 1).
#define	TIME_RATE_PSK31 4800
	The change in the CCP_1 register for each interrupt period. 1mS for PSK31, 104uS for 9600 baud APRS, 3.3mS for 300 baud HF-APRS.
#define	TIME_RATE_APRS 500
#define	TIME_RATE_HF_APRS 16000
#define	TIME_ROLLOVER_PSK31 100
	The number of interrupts in a 100mS time period.
#define	TIME_ROLLOVER_APRS 960
#define	TIME_ROLLOVER_HF_APRS 30
#define	TNC_TX_DELAY 45
	The number of start flag bytes to send before the packet message. (300mS).
#define	TNC_TIMESLOT 55
	The UTC time in seconds to send an APRS packet.
#define	TNC_BUFFER_SIZE 80
#define	TNC_DWELL_TIME 3600
Typedefs
typedef boolean	bool_t
	Boolean value { false, true }.
typedef signed int8	int8_t
	Signed 8-bit number in the range -128 through 127.
typedef unsigned int8	uint8_t
	Unsigned 8-bit number in the range 0 through 255.
typedef signed int16	int16_t
	Signed 16-bit number in the range -32768 through 32767.
typedef unsigned int16	uint16_t
	Unsigned 16-bit number in the range 0 through 65535.
typedef signed int32	int32_t
	Signed 32-bit number in the range -2147483648 through 2147483647.
typedef unsigned int32	uint32_t
	Unsigned 32-bit number in the range 0 through 4294967296.
Enumerations
enum	DDS_MODE { DDS_MODE_POWERDOWN, DDS_MODE_APRS, DDS_MODE_PSK31, DDS_MODE_HF_APRS }
	Constants to select the DDS mode in method ddsSetMode. More...
enum	GPS_FIX_TYPE { GPS_NO_FIX, GPS_2D_FIX, GPS_3D_FIX }
	Type of GPS fix. More...
enum	LOG_TYPE { LOG_BOOTED = 0xb4, LOG_COORD = 0xa5, LOG_TEMPERATURE_1 = 0x96, LOG_VOLTAGE = 0x87, LOG_TEMPERATURE_2 = 0x78, LOG_PUMP = 0x69 }
	Define the log record types. More...
enum	TIME_MODE { TIME_MODE_APRS, TIME_MODE_PSK31, TIME_MODE_HF_APRS }
enum	TNC_PACKET_TYPE { TNC_BOOT_MESSAGE, TNC_STATUS, TNC_GGA, TNC_RMC }
enum	BALLAST_MODE { WAIT_ACTIVATION, CONTROL_ALTITUDE, PUMP_RUN, PUMP_RUN_DELAY }
	Ballast pump state machine. More...
enum	GPS_PARSE_STATE_MACHINE { GPS_START1, GPS_START2, GPS_COMMAND1, GPS_COMMAND2, GPS_READMESSAGE, GPS_CHECKSUMMESSAGE, GPS_EOMCR, GPS_EOMLF }
	GPS parse engine state machine values. More...
enum	PSK_MODE { PSK_WAIT_MSG, PSK_TX_SYNC, PSK_TX_MESSAGE, PSK_TX_END }
	PSK-31 state machine. More...
enum	TNC_MODE { TNC_TX_READY, TNC_TX_SYNC, TNC_TX_HEADER, TNC_TX_DATA, TNC_TX_END }
	TNC state machine. More...
Functions
bool_t	cutDownIsActivate ()
	Determine if cut down has been activated.
void	ddsInit ()
	Initialize the DDS regsiters and RAM.
void	ddsPhase (bool_t phase)
	Set the output phase.
void	ddsSetOutputScale (uint16_t scale)
	Set DDS amplitude value in the range 0 to 16383 where 16383 is full scale.
void	ddsSetAmplitude (uint8_t amplitude)
	Set the DDS amplitude in units of dBc of full scale where 1 is 0.1 dB.
void	ddsPTT (bool_t state)
	Turn on the DDS output.
void	ddsSetFreq (uint32_t freq)
	Convert frequency in hertz to 32-bit DDS FTW (Frequency Tune Word).
void	ddsSetFTW (uint32_t ftw)
	Set DDS frequency tuning word.
void	ddsSetMode (DDS_MODE mode)
	Set the DDS to run in A-FSK, FSK, or PSK31 mode.
void	flashErase ()
	Erase the entire flash device (all locations set to 0xff).
uint8_t	flashGetByte ()
	Read a single byte from the flash device through the serial interface.
uint8_t	flashReadElectronicSignature ()
	Read the flash electronic signature byte.
void	flashReadBlock (uint32_t address, uint8_t *block, uint16_t length)
	Read a block of memory from the flash device.
void	flashSendByte (uint8_t value)
	Write a single byte to the flash device through the serial interface.
void	flashSendAddress (uint32_t address)
	Write the 24-bit address to the flash device through the serial interface.
void	flashWriteBlock (uint32_t address, uint8_t *block, uint8_t length)
	Write a block of memory to the flash device.
uint8_t	flashReadES ()
void	gpsInit ()
	Initialize the GPS subsystem.
bool_t	gpsIsReady ()
	Determine if new GPS message is ready to process.
GPS_FIX_TYPE	gpsGetFixType ()
	Get the type of fix.
int32_t	gpsGetPeakAltitude ()
	Peak altitude detected while GPS is in 3D fix mode since the system was booted.
void	gpsPowerOn ()
	Turn on the GPS engine power and serial interface.
void	gpsPowerOff ()
	Turn off the GPS engine power and serial interface.
bool_t	gpsSetup ()
	Verify the GPS engine is sending the @Hb position report message.
void	gpsUpdate ()
	Read the serial FIFO and process complete GPS messages.
int16_t	lm92GetTemp ()
	Read the LM92 temperature value in 0.1 degrees F.
void	logInit ()
	Prepare the flight data recorder for logging.
uint32_t	logGetAddress ()
	Last used address in flash memory.
void	logSetDisableFlag (bool_t disableFlag)
	Enable and disable flash write operations.
void	logType (LOG_TYPE type)
	Start a entry in the data log.
void	logUint8 (uint8_t value)
	Save an unsigned, 8-bit value in the log.
void	logInt16 (int16_t value)
	Save a signed, 16-bit value in the log.
void	logInt32 (int32_t value)
	Save a signed, 32-bit value in the log.
bool_t	psk31CreateDataPacket ()
	Create the PSK 31 packet.
void	psk31Init ()
	Initialize the PSK 31 modulator.
void	psk31TimeUpdate ()
	This method should be called every 1 milliseconds by the timer interrupt.
void	psk31TxPacket (uint8_t minutes)
	Generate and start transmision of PSK-31 message.
void	psk31TxByte (uint8_t value)
	Write value to the PSK 31 buffer.
void	psk31TxNull ()
void	psk31TxString (char *string, uint8_t length)
	Write length characters of string.
bool_t	serialHasData ()
	Determine if the FIFO contains data.
void	serialInit ()
	Initialize the serial processor.
uint8_t	serialRead ()
	Get the oldest character from the FIFO.
void	serialUpdate ()
	Read and store any characters in the PIC serial port in a FIFO.
uint16_t	sysCRC16 (uint8_t *buffer, uint8_t length, uint16_t crc)
	Calculate the CRC-16 CCITT of buffer that is length bytes long.
void	sysPAOutput (bool_t state)
	Control the PA output.
uint8_t	timeGetTicks ()
	Running 8-bit counter that ticks every 100mS.
void	timeInit ()
	Initialize the real-time clock.
uint8_t	timeGetHours ()
	Get the time since boot in hours.
uint8_t	timeGetMinutes ()
	Get the time since boot in minutes.
void	timeSetDutyCycle (uint8_t dutyCycle)
	Set the blink duty cycle of the heartbeat LED.
void	timeSetMode (TIME_MODE mode)
	Set the time base for PSK31 or APRS.
void	timeUpdate ()
void	tncInit ()
bool_t	tncIsFree ()
	Determine if the hardware if ready to transmit a 1200 baud packet.
void	tncTimeUpdate ()
void	tncTxByte (uint8_t value)
	Write value to the TNC buffer.
void	tncTxPacket (TNC_PACKET_TYPE tncPacketType)
	Prepare an AX.25 data packet.
uint16_t	ballastGetPumpCount ()
	Return the number of times the ballast pump has been commanded to run.
void	ballastInit ()
	Setup the ballast controls system.
void	ballastSetState (bool_t state)
	Set the ballast control operation.
void	ballastLogEvent (bool_t state)
	Log the ballast pump command on or off.
void	ballastCheck ()
	Function that should be called once a second with each GPS fix to determine ballast pump operation.
void	cutDownInit ()
	Initialize the cut down control system.
void	cutDownActivate ()
	Activate the I/O and timers for the cutdown.
void	cutDownCheck ()
	Fucntion that is called each time a new GPS message position report is received.
void	diagEraseFlash ()
	Process the command to erase the data logger flash.
void	diagReadFlash ()
	Process the command to dump the contents of the data logger flash.
void	diagMenu ()
	Display the engineering mode menu.
void	diagPort ()
	Process commands through the external RS-232 port.
bool_t	flashIsWriteInProgress ()
	Determine if a flash write or erase operation is currently in progress.
void	flashInit ()
	Initialize the flash memory subsystem.
uint8_t	gpsNMEAChecksum (uint8_t *buffer, uint8_t length)
	Calculate NMEA-0183 message checksum of buffer that is length bytes long.
void	gpsParsePositionMessage ()
	Parse the Motorola @Hb (Short position/message) report.
void	logFlush ()
	Write the contents of the temporary log buffer to the flash device.
void	logUint16 (uint16_t value)
	Save an unsigned, 16-bit value in the log.
bool_t	psk31IsFree ()
	Determine if the hardware if ready to a PSK 31 packet.
bool_t	psk31IsMessageDone ()
void	sysLogGPSData ()
	Log the current GPS position.
void	timeSetRunFlag ()
	Set a flag to indicate the flight time should run.
void	tncNMEATime ()
	Generate the GPS NMEA standard UTC time stamp.
void	tncNMEAFix ()
	Generate the GPS NMEA standard latitude/longitude fix.
void	tncStatusPacket ()
	Generate the plain text status packet.
void	tncGPGGAPacket ()
	Generate the GPS NMEA-0183 $GPGGA packet.
void	tncGPRMCPacket ()
	Generate the GPS NMEA-0183 $GPRMC packet.
void	main ()
Variables
GPSPOSITION_STRUCT	gpsPosition
	Last verified GPS message received.
uint16_t	ballastPumpCount
	Number of times the ballast pump has been commanded to run.
uint8_t	ballast3DFixCount
	Count of 3D fixes required to assert GPS altitude is valid.
uint8_t	ballastTimeCount
	Counter used to track number of seconds pump is on or off.
BALLAST_MODE	ballastMode
	Enumerated type that indicates the current ballast mode.
bool_t	ballastState
	Flag used to enable/disable ballast control.
uint8_t	cutDownTimer
	Counter used to track how long the nichrome wire has been active.
uint8_t	cutDown3DFixCount
	Count of 3D fixes required to assert GPS altitude is valid.
bool_t	cutDownFlag
	Flag that is set when the cut down has been fired.
const uint32_t	DDS_MULT [DDS_FREQ_TO_FTW_DIGITS] = { 11, 1, 8, 4, 8, 1, 0, 6, 6 }
	Array of multiplication factors used to convert frequency to the FTW.
const uint32_t	DDS_DIVISOR [DDS_FREQ_TO_FTW_DIGITS-1] = { 10, 100, 1000, 10000, 100000, 1000000, 10000000, 100000000 }
	Array of divisors used to convert frequency to the FTW.
const uint16_t	DDS_AMP_TO_SCALE []
	Lookup table to convert dB amplitude scale in 0.5 steps to a linear DDS scale factor.
const uint32_t	freqTable [256]
uint8_t	gpsIndex
	Index into gpsBuffer used to store message data.
GPS_PARSE_STATE_MACHINE	gpsParseState
	State machine used to parse the GPS message stream.
uint8_t	gpsBuffer [GPS_BUFFER_SIZE]
	Buffer to store data as it is read from the GPS engine.
int32_t	gpsPeakAltitude
	Peak altitude detected while GPS is in 3D fix mode.
uint8_t	gpsChecksum
	Checksum used to verify binary message from GPS engine.
uint32_t	logAddress
	Last used address in flash memory.
uint8_t	logBuffer [LOG_WRITE_BUFFER_SIZE]
	Temporary buffer that holds data before it is written to flash device.
uint8_t	logIndex
	Current index into log buffer.
bool_t	logDisableFlag
	Flag that disable writes to flash.
const uint16_t	PSK31_VARICODE []
const uint32_t	PSK31_FREQ_LIST [] = { 14070450, 14070450, 14070450 }
	PSK 31 frequency and amplitude list for minutes 0 through 2 modulo 2.
const uint16_t	PSK31_AMP_LIST [] = { 105, 105, 105 }
uint8_t	pskCount
	Counts the number of 1mS time slices in each 32mS of a bit time.
uint16_t	pskData
	The current PSK output character.
bool_t	pskPhase
	The current DDS phase offset where true is 180 degreees and false is 0 degrees.
char	pskBuffer [PSK_MAX_PACKET]
	Buffer that holds PSK packet.
PSK_MODE	pskMode
	State machine variable that indicates current transmit state.
uint8_t	pskLastBits
	Last 4 bits that were transmitted.
uint8_t	pskIndex
	Index into the PSK packet buffer.
bool_t	pskMessageDoneFlag
	Flag that is set when PSK-31 message is completed.
uint8_t	serialHead
	Index to the next free location in the buffer.
uint8_t	serialTail
	Index to the next oldest data in the buffer.
uint8_t	serialBuffer [SERIAL_BUFFER_SIZE]
	Buffer to hold serial data.
uint8_t	timeTicks
	A counter that ticks every 100mS.
uint16_t	timeInterruptCount
	Counts the number of 1mS interrupts for a 100mS time period.
uint8_t	time100ms
	Counts the number of 100mS time periods in 1 second.
uint8_t	timeSeconds
	System time in seconds.
uint8_t	timeMinutes
	System time in minutes.
uint8_t	timeHours
	System time in hours.
uint8_t	timeDutyCycle
	Desired LED duty cycle 0 to 9.
uint16_t	timeCompare
	Time compare register 1 value.
uint16_t	timeRate
	The CCP1 timer delta between each interrupt.
bool_t	timeUpdateFlag
	Flag set true once per second.
bool_t	timeRunFlag
	Flag that indicate the flight time should run.
uint16_t	timeInterruptCountRollOver
	The number of interrupts in a 100mS time period. The value changes based on the current mode.
TIME_MODE	timeMode
	The current time base mode.
uint8_t	TNC_AX25_HEADER [30]
uint8_t	tncLastBit
uint8_t	tncPacketType
TNC_MODE	tncMode
	Current mode of the 1200 bps state machine.
uint8_t	tncBitCount
	Counter for each bit (0 - 7) that we are going to transmit.
uint8_t	tncShift
	A shift register that holds the data byte as we bit shift it for transmit.
uint8_t	tncIndex
	Index into the APRS header and data array for each byte as we transmit it.
uint8_t	tncLength
	The number of bytes in the message portion of the AX.25 message.
uint8_t	tncBitStuff
	A copy of the last 5 bits we've transmitted to determine if we need to bit stuff on the next bit.
uint8_t *	tncBufferPnt
	Pointer to TNC buffer as we save each byte during message preparation.
uint8_t	tncBuffer [TNC_BUFFER_SIZE]
	Buffer to hold the message portion of the AX.25 packet as we prepare it.
uint16_t	tncTestCount
uint16_t	timeNCO
	16-bit NCO where the upper 8-bits are used to index into the frequency generation table.
uint16_t	timeNCOFreq
	Audio tone NCO update step (phase).
uint8_t	timeLowRateCount
	Counter used to deciminate down from the 104uS to 833uS interrupt rate. (9600 to 1200 baud).

Define Documentation

#define IO_BALLAST_PUMP PIN_A2

Referenced by ballastCheck(), and diagPort().

#define IO_CS PIN_B0

Referenced by ddsInit(), ddsPhase(), ddsSetFTW(), ddsSetMode(), and ddsSetOutputScale().

#define IO_CUT_DOWN PIN_A1

Referenced by cutDownActivate(), cutDownCheck(), diagPort(), and main().

#define IO_FLASH_CS PIN_A0

Flash Chip Select - Port A0.

Referenced by flashErase(), flashInit(), flashIsWriteInProgress(), flashReadBlock(), flashReadElectronicSignature(), and flashWriteBlock().

#define IO_GPS_PWR PIN_B3

Referenced by gpsPowerOff(), gpsPowerOn(), and main().

#define IO_LED PIN_B4

Referenced by diagPort(), main(), and timeUpdate().

#define IO_OSK PIN_C2

Referenced by ddsInit(), ddsPTT(), ddsSetAmplitude(), diagPort(), and psk31TimeUpdate().

#define IO_PA PIN_B2

Referenced by main(), and sysPAOutput().

#define IO_PS0 PIN_A3

Referenced by ddsInit().

#define IO_PS1 PIN_C0

Referenced by ddsInit().

#define IO_UPDATE PIN_A5

Referenced by ddsInit(), ddsPhase(), ddsSetFTW(), ddsSetMode(), and ddsSetOutputScale().

#define TIME_DUTYCYCLE_0 0

Referenced by main().

#define TIME_DUTYCYCLE_20 2

Referenced by gpsSetup().

#define TIME_DUTYCYCLE_70 7

Referenced by timeInit().

Typedef Documentation

typedef boolean bool_t

Boolean value { false, true }.

typedef signed int16 int16_t

Signed 16-bit number in the range -32768 through 32767.

typedef signed int32 int32_t

Signed 32-bit number in the range -2147483648 through 2147483647.

typedef signed int8 int8_t

Signed 8-bit number in the range -128 through 127.

typedef unsigned int16 uint16_t

Unsigned 16-bit number in the range 0 through 65535.

typedef unsigned int32 uint32_t

Unsigned 32-bit number in the range 0 through 4294967296.

typedef unsigned int8 uint8_t

Unsigned 8-bit number in the range 0 through 255.

Enumeration Type Documentation

enum DDS_MODE

Constants to select the DDS mode in method ddsSetMode.

Enumerator:

DDS_MODE_POWERDOWN	Place the DDS in low power mode.
DDS_MODE_APRS	1200 baud A-FSK APRS
DDS_MODE_PSK31	PSK-31.
DDS_MODE_HF_APRS	300 baud FSK APRS

enum GPS_FIX_TYPE

Type of GPS fix.

Enumerator:

GPS_NO_FIX	No GPS FIX.
GPS_2D_FIX	2D (Latitude/Longitude) fix.
GPS_3D_FIX	3D (Latitude/Longitude/Altitude) fix.

enum LOG_TYPE

Define the log record types.

Enumerator:

LOG_BOOTED	Time stamp the log was started.
LOG_COORD	GPS coordinates.
LOG_TEMPERATURE_1	Temperature Value 1.
LOG_VOLTAGE	Bus voltage.
LOG_TEMPERATURE_2	Temperature Value 2.
LOG_PUMP	Pump activity and altitude.
